Hikvision DS-QAE0A120G1-VB6 120W 6-Zone Analog Amplifier, 2x AUX, 1x EMC, 2x Microphone Inputs, Built in Bluetooth/MP3

FromOMR 69.226
Hikvision DS-QAE0A120G1-VB6 120W 6-Zone Analog Amplifier, 2x AUX, 1x EMC, 2x Microphone Inputs, Built in Bluetooth/MP3—
OMR 69.226
  • Fast delivery

    Ships in 2–4 business days across Oman.

  • Easy returns

    30-day money-back guarantee, no fuss.

  • Secure checkout

    Encrypted payments you can trust.

Description

The Hikvision DS-QAE0A120G1-VB6 120W 6-Zone Analog Amplifier is a professional-grade public address and background music solution designed for commercial, retail, educational, hospitality, and industrial audio installations. Combining powerful amplification, multi-zone audio control, Bluetooth connectivity, and versatile input options, this high-performance amplifier delivers reliable and flexible sound distribution for modern PA systems.

Engineered with a powerful 120W output capacity, the amplifier supports up to 6 independent audio zones, allowing users to manage and distribute audio efficiently across multiple areas such as offices, shopping malls, schools, restaurants, mosques, warehouses, hotels, and commercial buildings. Each zone can be controlled individually for enhanced flexibility and customized audio management.

The DS-QAE0A120G1-VB6 features built-in Bluetooth and MP3 playback functionality, enabling convenient wireless music streaming and direct audio playback without additional devices. Multiple audio input options including 2 AUX inputs and 2 microphone inputs provide seamless connectivity for microphones, media players, paging systems, and external audio equipment.

An integrated EMC (Emergency Microphone Control) input ensures priority emergency broadcasting capabilities, making the amplifier suitable for safety announcements and evacuation systems in commercial environments. The dual microphone support makes it ideal for public speaking, announcements, presentations, and paging applications.

Designed for continuous professional operation, the amplifier offers stable performance, efficient heat management, and easy integration into centralized audio systems. Its durable construction and user-friendly controls make it an ideal solution for both small and large-scale audio installations.

Whether used for background music, voice announcements, paging systems, or multi-zone public address applications, the Hikvision DS-QAE0A120G1-VB6 delivers reliable audio amplification with modern connectivity and intelligent zone management.

Specifications

SKUDS-QAE0A120G1-VB6 Amplifi
USBUSB2.0
ColorBlack
Power200V-230V , 50/60Hz 5A
WeightApprox. 9.2 kg (20.28 lb.)
Audio InEMC IN   1, 6.5 mm Microphone  2, AUX IN    2, Bluetooth, USB2.0, SD card
MaterialIron
Audio OutConstant Voltage Output   1, 110 V COM, Constant Voltage Output   1, 70 V COM, Constant Impedance Output   1, 4~16  COM, Partition Output   6, 110 V COM, Line out   1
Dimension484   88 ? 360mm
Rated Power120W
SensitivityLine: -10dB EMC: -10dB MIC: -40dB Line: 0dB
THD And SNRTHD 0.5% SNR 83dB
Volume KnobMIC Volume Knob   2, Partition 1 Volume Knob   6, All Volume Knob   1, Bass Volume Knob   1, Treble Volume Knob   1, AUX1/MP3 Volume Knob   1, AUX2 Volume Knob   1, EMC Volume Knob   1
InstallationCabinet installation
Packing ListOne machine and one power cord
Source Categorynetworking/amplifier
Package Dimension484    88  395mm
Frequency Response80Hz-18KHz ( 3dB)
With Package WeightApprox. 9.5 Kg (20.94 lb.)
Operating Temperature-10~+40 C ( 2), 20%~80% relative humidity
