Unifi Dream Machine Special Edition UDM-SE 10G Cloud Gateway, 100+ UniFi device / 1,000+ client support, 3.5 Gbps IPS Routing, Built-in PoE Switching | UDM-SE (180W)

FromOMR 285.695
Unifi Dream Machine Special Edition UDM-SE 10G Cloud Gateway, 100+ UniFi device / 1,000+ client support, 3.5 Gbps IPS Routing, Built-in PoE Switching | UDM-SE (180W)—
OMR 285.695

  • Fast delivery

    Ships in 2–4 business days across Oman.

  • Easy returns

    30-day money-back guarantee, no fuss.

  • Secure checkout

    Encrypted payments you can trust.

Description

table { border-collapse: collapse; width: 100%; } tr { border-bottom: 1px solid rgb(222, 226, 230); } td { padding: 8px; margin: 0; } td:first-child { font-weight: bold; color: #333; } h3 { margin-top: 10px; }

Unifi Dream Machine Special Edition UDM-SE 10G Cloud Gateway | UDM-SE (180W) Specifications

UniFi Application SuiteFull
UniFi Devices200+
Client Devices200+
WiFi-
High AvailabilityShadow Mode
Multi-WAN Load BalancingYes
Application-Aware FirewallYes
Mechanical Dimensions442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
Weight5 kg (10.9 lb)
Enclosure MaterialAluminium CNC, SGCC steel
Mount MaterialSGCC steel
Hardware ProcessorQuad-core ARM?? Cortex??-A57 at 1.7 GHz
System Memory4 GB DDR4
On-board Storage16 GB eMMC
Integrated Storage128 GB SSD
Management InterfaceEthernet
BluetoothYes
Networking Interface (LAN)(8) GbE RJ45 ports, (1) 10G SFP+ port
Networking Interface (WAN)(1) 2.5 GbE RJ45 port, (1) 10G SFP+ port
PoE Interface(6) PoE (Pair A 1, 2+; 3, 6-), (2) PoE+ (Pair A 1, 2+; 3, 6-)
IDS/IPS Throughput3.5 Gbps*
Power Method(1) Universal AC input, 100???240V AC, 4.4A Max., 50/60 Hz, (1) USP-RPS DC input, 52V DC, 3.94A
Power SupplyAC/DC, internal, 240W
Supported Voltage Range100???240V AC
Max. Power Consumption50W (Excluding PoE output)
PoE Budget180W
Max. PoE Wattage Per Port by PSEPoE: 15.4W, PoE+: 30W
Voltage Range PoE ModePoE: 44???57V, PoE+: 50???57V
ESD/EMP ProtectionAir: ?? 15kV, contact: ?? 8kV
LCM Display(1) 1.3" touchscreen
ButtonFactory reset
Ambient Operating Temperature-10 to 40?? C (14 to 104?? F)
Ambient Operating Humidity5 to 95% noncondensing
CertificationsCE, FCC, IC
Gateway FeaturesRedundant WAN with failover and load balancing
WiFi QoSWith UniFi APs
Application, Domain, and Country-Based QoSYes
Application and Device Type IdentificationYes
Additional Internet Failover with LTE BackupYes
Internet Quality and Outage ReportingYes
Next-Generation SecurityApplication-aware firewall rules, Signature-based IPS/IDS threat detection, Content, country, domain, and ad filtering
VLAN/Subnet-Based Traffic SegmentationYes
Full Stateful FirewallYes
Advanced NetworkingLicense-free SD-WAN, WireGuard, L2TP and OpenVPN server, OpenVPN client, OpenVPN and IPsec site-to-site VPN, One-click Teleport and Identity VPN, Policy-based WAN and VPN routing, DHCP relay, Customizable DHCP server, IGMP proxy, IPv6 ISP support
LEDs (Ethernet)White: link/activity
LEDs (SFP+)White: link/activity
LEDs (HDD)White: disk activity, Amber: disk error
LEDs (RPS)Blue: ready

Specifications

SKUNS-UNIFI UDM-SE
WiFi-
Weight5 kg (10.9 lb)
BluetoothYes
PoE Interface(6) PoE (Pair A 1, 2+; 3, 6-), (2) PoE+ (Pair A 1, 2+; 3, 6-)
System Memory4 GB DDR4
UniFi Devices200+
Client Devices200+
Mount MaterialSGCC steel
Source Categorysecurity-surveillance/gateway
On Board Storage16 GB eMMC
High AvailabilityShadow Mode
Enclosure MaterialAluminium CNC, SGCC steel
Hardware ProcessorQuad-core ARM?? Cortex??-A57 at 1.7 GHz
Integrated Storage128 GB SSD
Management InterfaceEthernet
Mechanical Dimensions442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
UniFi Application SuiteFull
Multi WAN Load BalancingYes
Application Aware FirewallYes
Networking Interface (LAN)(8) GbE RJ45 ports, (1) 10G SFP+ port
Networking Interface (WAN)(1) 2.5 GbE RJ45 port, (1) 10G SFP+ port
